ovrnaalifoldpf |
Please help by correcting and extending the Wiki pages.
This is a port of the Vienna RNA package program RNAalifold.
It reads aligned RNA sequences and calculates their minimum free energy (mfe) structure, partition function (pf) and base pairing probability matrix. It returns the mfe structure in bracket notation, its energy, the free energy of the thermodynamic ensemble and the frequency of the mfe structure in the ensemble. It also produces plots of the resulting secondary structure graph and a "dot plot" of the base pairing matrix.
The original program produces different outputs, depending on the options selected. In the EMBASSY implementation it is split into ovrnaalifold and ovrnaalifoldpf
% ovrnaalifoldpf Calculate secondary structures for a set of aligned RNAs (partition) Input (aligned) nucleotide sequence set: ecoli6s.fasta Vienna RNAfold output file [ecoli6s.ovrnaalifoldpf]: |
Go to the input files for this example
Go to the output files for this example
Calculate secondary structures for a set of aligned RNAs (partition)
Version: EMBOSS:6.5.0.0
Standard (Mandatory) qualifiers:
[-sequence] seqset (Aligned) nucleotide sequence set filename
and optional format, or reference (input
USA)
[-outfile] outfile [*.ovrnaalifoldpf] Vienna RNAfold output
file
Additional (Optional) qualifiers: (none)
Advanced (Unprompted) qualifiers:
-constraintfile infile Vienna RNA structure constraints file
(optional)
-paramfile infile Vienna RNA parameters file (optional)
-temperature float [37.0] Temperature (Any numeric value)
-[no]gu boolean [Y] Allow GU pairs
-[no]closegu boolean [Y] Allow GU pairs at end of helices
-[no]lp boolean [Y] Allow lonely pairs
-[no]convert boolean [Y] Convert T to U
-nsbases string Non-standard bases (Any string)
-[no]tetraloop boolean [Y] Stabilizing energies for tetra-loops
-circular boolean [N] Circular RNA
-colour boolean [N] Colour structure plot
-energy menu [0] Rarely used option to fold sequences
from the ABCD... alphabet (Values: 0 (BP); 1
(Any with GC); 2 (Any with AU parameters))
-scale float [1.07] Estimate of ensemble free energy (Any
numeric value)
-dangles menu [2] Method (Values: 0 (Ignore); 1 (Only
unpaired bases for just one dangling end); 2
(Always use dangling energies); 3 (Allow
coaxial stacking of adjacent helices))
-covariance float [1.0] Weight for covariance (Any numeric
value)
-nspenalty float [1.0] Non-compatible sequence penalty (Any
numeric value)
-endgaps boolean [N] Mark end gaps
-most boolean [N] Use most informative sequence algorithm
-dotoutfile outfile [*.ovrnaalifoldpf] Vienna dotplot postscript
output file (optional)
-ssoutfile outfile [*.ovrnaalifoldpf] Vienna RNA structure
postscript output file
-alignoutfile outfile [*.ovrnaalifoldpf] Vienna RNA alignment
postscript output file (optional)
Associated qualifiers:
"-sequence" associated qualifiers
-sbegin1 integer Start of each sequence to be used
-send1 integer End of each sequence to be used
-sreverse1 boolean Reverse (if DNA)
-sask1 boolean Ask for begin/end/reverse
-snucleotide1 boolean Sequence is nucleotide
-sprotein1 boolean Sequence is protein
-slower1 boolean Make lower case
-supper1 boolean Make upper case
-scircular1 boolean Sequence is circular
-sformat1 string Input sequence format
-iquery1 string Input query fields or ID list
-ioffset1 integer Input start position offset
-sdbname1 string Database name
-sid1 string Entryname
-ufo1 string UFO features
-fformat1 string Features format
-fopenfile1 string Features file name
"-outfile" associated qualifiers
-odirectory2 string Output directory
"-dotoutfile" associated qualifiers
-odirectory string Output directory
"-ssoutfile" associated qualifiers
-odirectory string Output directory
"-alignoutfile" associated qualifiers
-odirectory string Output directory
General qualifiers:
-auto boolean Turn off prompts
-stdout boolean Write first file to standard output
-filter boolean Read first file from standard input, write
first file to standard output
-options boolean Prompt for standard and additional values
-debug boolean Write debug output to program.dbg
-verbose boolean Report some/full command line options
-help boolean Report command line options and exit. More
information on associated and general
qualifiers can be found with -help -verbose
-warning boolean Report warnings
-error boolean Report errors
-fatal boolean Report fatal errors
-die boolean Report dying program messages
-version boolean Report version number and exit
|
| Qualifier | Type | Description | Allowed values | Default | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Standard (Mandatory) qualifiers | ||||||||||||
| [-sequence] (Parameter 1) |
seqset | (Aligned) nucleotide sequence set filename and optional format, or reference (input USA) | Readable set of sequences | Required | ||||||||
| [-outfile] (Parameter 2) |
outfile | Vienna RNAfold output file | Output file | <*>.ovrnaalifoldpf | ||||||||
| Additional (Optional) qualifiers | ||||||||||||
| (none) | ||||||||||||
| Advanced (Unprompted) qualifiers | ||||||||||||
| -constraintfile | infile | Vienna RNA structure constraints file (optional) | Input file | Required | ||||||||
| -paramfile | infile | Vienna RNA parameters file (optional) | Input file | Required | ||||||||
| -temperature | float | Temperature | Any numeric value | 37.0 | ||||||||
| -[no]gu | boolean | Allow GU pairs | Boolean value Yes/No | Yes | ||||||||
| -[no]closegu | boolean | Allow GU pairs at end of helices | Boolean value Yes/No | Yes | ||||||||
| -[no]lp | boolean | Allow lonely pairs | Boolean value Yes/No | Yes | ||||||||
| -[no]convert | boolean | Convert T to U | Boolean value Yes/No | Yes | ||||||||
| -nsbases | string | Non-standard bases | Any string | |||||||||
| -[no]tetraloop | boolean | Stabilizing energies for tetra-loops | Boolean value Yes/No | Yes | ||||||||
| -circular | boolean | Circular RNA | Boolean value Yes/No | No | ||||||||
| -colour | boolean | Colour structure plot | Boolean value Yes/No | No | ||||||||
| -energy | list | Rarely used option to fold sequences from the ABCD... alphabet |
|
0 | ||||||||
| -scale | float | Estimate of ensemble free energy | Any numeric value | 1.07 | ||||||||
| -dangles | list | Method |
|
2 | ||||||||
| -covariance | float | Weight for covariance | Any numeric value | 1.0 | ||||||||
| -nspenalty | float | Non-compatible sequence penalty | Any numeric value | 1.0 | ||||||||
| -endgaps | boolean | Mark end gaps | Boolean value Yes/No | No | ||||||||
| -most | boolean | Use most informative sequence algorithm | Boolean value Yes/No | No | ||||||||
| -dotoutfile | outfile | Vienna dotplot postscript output file (optional) | Output file | <*>.ovrnaalifoldpf | ||||||||
| -ssoutfile | outfile | Vienna RNA structure postscript output file | Output file | <*>.ovrnaalifoldpf | ||||||||
| -alignoutfile | outfile | Vienna RNA alignment postscript output file (optional) | Output file | <*>.ovrnaalifoldpf | ||||||||
| Associated qualifiers | ||||||||||||
| "-sequence" associated seqset qualifiers | ||||||||||||
| -sbegin1 -sbegin_sequence |
integer | Start of each sequence to be used | Any integer value | 0 | ||||||||
| -send1 -send_sequence |
integer | End of each sequence to be used | Any integer value | 0 | ||||||||
| -sreverse1 -sreverse_sequence |
boolean | Reverse (if DNA) | Boolean value Yes/No | N | ||||||||
| -sask1 -sask_sequence |
boolean | Ask for begin/end/reverse | Boolean value Yes/No | N | ||||||||
| -snucleotide1 -snucleotide_sequence |
boolean | Sequence is nucleotide | Boolean value Yes/No | N | ||||||||
| -sprotein1 -sprotein_sequence |
boolean | Sequence is protein | Boolean value Yes/No | N | ||||||||
| -slower1 -slower_sequence |
boolean | Make lower case | Boolean value Yes/No | N | ||||||||
| -supper1 -supper_sequence |
boolean | Make upper case | Boolean value Yes/No | N | ||||||||
| -scircular1 -scircular_sequence |
boolean | Sequence is circular | Boolean value Yes/No | N | ||||||||
| -sformat1 -sformat_sequence |
string | Input sequence format | Any string | |||||||||
| -iquery1 -iquery_sequence |
string | Input query fields or ID list | Any string | |||||||||
| -ioffset1 -ioffset_sequence |
integer | Input start position offset | Any integer value | 0 | ||||||||
| -sdbname1 -sdbname_sequence |
string | Database name | Any string | |||||||||
| -sid1 -sid_sequence |
string | Entryname | Any string | |||||||||
| -ufo1 -ufo_sequence |
string | UFO features | Any string | |||||||||
| -fformat1 -fformat_sequence |
string | Features format | Any string | |||||||||
| -fopenfile1 -fopenfile_sequence |
string | Features file name | Any string | |||||||||
| "-outfile" associated outfile qualifiers | ||||||||||||
| -odirectory2 -odirectory_outfile |
string | Output directory | Any string | |||||||||
| "-dotoutfile" associated outfile qualifiers | ||||||||||||
| -odirectory | string | Output directory | Any string | |||||||||
| "-ssoutfile" associated outfile qualifiers | ||||||||||||
| -odirectory | string | Output directory | Any string | |||||||||
| "-alignoutfile" associated outfile qualifiers | ||||||||||||
| -odirectory | string | Output directory | Any string | |||||||||
| General qualifiers | ||||||||||||
| -auto | boolean | Turn off prompts | Boolean value Yes/No | N | ||||||||
| -stdout | boolean | Write first file to standard output | Boolean value Yes/No | N | ||||||||
| -filter | boolean | Read first file from standard input, write first file to standard output | Boolean value Yes/No | N | ||||||||
| -options | boolean | Prompt for standard and additional values | Boolean value Yes/No | N | ||||||||
| -debug | boolean | Write debug output to program.dbg | Boolean value Yes/No | N | ||||||||
| -verbose | boolean | Report some/full command line options | Boolean value Yes/No | Y | ||||||||
| -help | boolean | Report command line options and exit. More information on associated and general qualifiers can be found with -help -verbose | Boolean value Yes/No | N | ||||||||
| -warning | boolean | Report warnings | Boolean value Yes/No | Y | ||||||||
| -error | boolean | Report errors | Boolean value Yes/No | Y | ||||||||
| -fatal | boolean | Report fatal errors | Boolean value Yes/No | Y | ||||||||
| -die | boolean | Report dying program messages | Boolean value Yes/No | Y | ||||||||
| -version | boolean | Report version number and exit | Boolean value Yes/No | N | ||||||||
>X01238.1/1-183 AUUUCUCUGAGAUGUUCGCAAGCGGGC.CAGUCCCCUGAGCCGAUAUUUCAUACCACAAG AAUGUGGCGCUCCGCGGUUGGUGAGCAUGCUCGGUCCGU...............CCGAGA AGCCUUAAAACUGCGACGACACAUUCACCUUGAACCAA.GGGUUCAAGGGUUACAGCCUG CGGCGGCA.UC.UCGGAG.AUUC >AL627277.1/108623-108805 AUUUCUCUGAGAUGUUUGCAAGCGGGC.CAGUCCCCUGAGCCGAUAUUUCAUACCACAAG AAUGUGGCGCUCCGCGGUUGGUGAGCAUGCUCGGUUCGU...............CCGAGA AGCCUUAAAACUGUGACGACACAUUCACCUUGAACCAA.GGGUUCAAGGGUUACAGCCUG CGGCGGCA.UC.UCGGAG.AUUC >AJ414145.1/90993-91174 AUUUCUCUGAGGUGUUUGCCAGCGGGC.CAGUCCCCUGAGCCGAUAUUUAAUACCAACAG AAUGUAGUGCUCCGUAACCGGUGAGCAUGCUCGGUCCG................CCGAGA AGCCUUAAGGUUGCGACGCUGCGUUCACCUUGAACCAA.GGGUUCAAGGGUUACAGCCUG CGACGGCA.CC.UCGGAG.AUCC >U32767.1/6538-6734 .AUUACCUGGAGUGUUCGUCAGUAGGC.UAUGUCCCUGAGCCGAUACUUUAAAUCUUAUA AAUU.GGUUUCCUAUCGUUGGUGUGUAGGCUUAACCUUUGACUCGUUCAUUGGGCUAAGA AACCUGAAAACGGUAUCAACUGAUUU.CCUUGAACCGUCGGGUUCAAGGACUACUGCCCG CAGCGGCACUC.UGGGGU.CUUC >AE006208.1/8365-8185 .AUUACCUGAGGUGUUUGCCAGUGGGU.UAUGUCCCUGAGCCGAUACUUU.UAUUUUAUG AAUC.GGUUUCUAAUUGUUGGUGUGCAUGCUUAGCUUGA...............CUAAGA AGCCUAAAAAUAGUUAUAACUGAUUC.CCUUGAACCGUUGGGUUCAAGGACUGAGACUUG CAGCGGCA.UC.UCGGGUUCUUC >Y00334.1/77-254 CGCUCCCUGGUGUGUUGGCCAGUCGGU.GAUGUCCCUGAGCCGAUAACUGCAACAAC..G GAGGUUGC.CAGUUGGACCGGUGUGCAUGUCCGCACG.................ACGGAA AGCCUUAAGGUCUAC.UGCAACCGCCACCUUGAACUUUCGGGUUCAAGGGCUA.ACCCGA CAGCGGCA.CGACCGGGG.AGCU >AE004317.1/5626-5807 UUUACCCUGGGGUGUUCGUCAGCGGAUUUAUGUCCCUGAGCCGAUAAGCAACAUAAC..A GGGUUGGUAUUGGGUAGCUAUUGAGCAAGCUCGGCUUGUA..............CCGAGA AGCCUGCGGUUACCAUUACUGAUCCG.CCUUGAACCUGAUGGUUCAAGGGCUACGAUCCU CAACGGCA.UC.CCGGGG.UUC. |
![[ovrnaalifoldpf results]](ovrnaalifoldpf.1.ecoli6s.ss.gif)
![[ovrnaalifoldpf results]](ovrnaalifoldpf.1.ecoli6s.gif)
![[ovrnaalifoldpf results]](ovrnaalifoldpf.1.ecoli6s.alirna.gif)
AUUUCCCUGAGGUGUUCGCCAGCGGGC_CAUGUCCCUGAGCCGAUAUUUAAUACCACAAGAAUGUGGUGCUCCGUGGUUGGUGAGCAUGCUCGGCCCGU_______________CCGAGAAGCCUUAAAAUUGCGACGACACAUUCACCUUGAACCAA_GGGUUCAAGGGCUACAGCCUGCAGCGGCA_UC_UCGGGG_AUUC
....(((((((((((.(((..((((((................................(((((((......(((((((...(.((...(((((....................)))))..)))....)))))))....))))))).(((((((((....)))))))))......)))))).)))))).)).))))))..... (-56.91 = -48.71 + -8.20)
....(((((((((({{(((..((((((................................(((((((......(((((((...{.((...(((((....................)))))..)),....)))))))..,.))))))).(((((((((....)))))))))......)))))).)))))).)).))))))..... [-59.30]
frequency of mfe structure in ensemble 0.0206905
# Alignment section
7 sequences; length of alignment 203
alifold output
64 142 0 100.0% 0.000 CG:1 GC:4 UG:1 UA:1
63 143 0 99.9% 0.002 GC:1 GU:1 UG:1 UA:4
74 134 0 99.8% 0.005 GC:3 GU:1 AU:2 UA:1
77 131 0 100.0% 0.001 GC:3 GU:2 AU:2
10 193 0 99.8% 0.006 GC:2 GU:1 AU:4
76 132 1 99.9% 0.003 CG:1 GC:1 GU:2 AU:1 UA:1
79 129 0 99.3% 0.032 CG:2 UG:1 UA:4
66 140 0 98.3% 0.056 GC:4 GU:1 AU:1 UA:1
92 117 0 100.0% 0.000 CG:5 UA:2
91 118 0 100.0% 0.001 CG:1 UA:6
6 197 0 100.0% 0.001 CG:4 UA:3
90 119 0 99.9% 0.003 CG:6 UA:1
61 145 0 99.8% 0.005 GC:2 AU:5
93 116 0 99.8% 0.007 GC:5 AU:2
75 133 1 99.9% 0.003 CG:2 GU:1 UG:3
7 196 0 100.0% 0.000 CG:7
78 130 1 99.9% 0.010 CG:2 UA:4
8 195 0 99.8% 0.007 UG:7
62 144 1 99.7% 0.010 GC:1 AU:5
9 194 1 99.9% 0.003 GC:6
86 122 0 98.0% 0.083 CG:6 UA:1
65 141 2 99.1% 0.028 UG:2 UA:3
60 146 1 98.4% 0.050 GC:5 AU:1
152 165 0 98.0% 0.170 GC:7
155 162 0 98.0% 0.170 CG:7
85 123 0 97.9% 0.102 GC:7
153 164 0 97.9% 0.141 AU:7
154 163 0 97.9% 0.142 AU:7
151 166 0 97.5% 0.170 UA:7
5 198 0 96.3% 0.110 CG:5 AU:2
150 167 0 96.2% 0.158 UA:7
25 178 0 95.2% 0.329 GC:6 GU:1
26 177 0 95.1% 0.319 GC:6 AU:1
23 180 1 95.0% 0.199 CG:3 UG:2 UA:1
24 179 1 95.0% 0.320 CG:1 GC:1 GU:4
22 181 0 93.7% 0.311 GC:7
149 168 0 93.7% 0.404 CG:7
156 161 0 92.4% 0.322 CG:6 UG:1
27 176 1 91.6% 0.277 CG:4 UA:2
18 184 0 90.9% 0.490 GC:7
73 135 2 88.8% 0.331 CG:3 AU:1 UA:1
[Part of this file has been deleted for brevity]
25 36 0 0.6% 0.518 GC:7 +
24 37 1 0.6% 0.725 GU:5 AU:1 +
85 124 0 0.3% 0.462 GC:7 +
101 107 0 0.3% 0.080 AU:1 --:6 +
16 188 0 0.3% 0.831 UA:7 +
102 114 0 0.2% 0.070 CG:1 --:6 +
103 113 0 0.2% 0.070 UG:1 --:6 +
104 112 0 0.2% 0.052 CG:1 --:6 +
34 38 0 0.2% 0.894 CG:7 +
16 25 0 0.2% 0.927 UG:7 +
101 110 0 0.2% 0.061 AU:1 --:6 +
34 43 0 0.2% 0.658 CG:7 +
38 42 0 0.2% 0.938 GC:7 +
37 43 0 0.1% 0.727 UG:7 +
105 111 0 0.1% 0.030 GU:1 --:6 +
101 106 0 0.1% 0.063 AU:1 --:6 +
148 152 0 0.1% 0.237 CG:7 +
35 43 0 0.1% 0.641 CG:7 +
25 35 0 0.1% 0.629 GC:7 +
84 126 2 0.1% 0.039 UG:1 AU:3 UA:1 +
103 114 0 0.1% 0.071 UG:1 --:6 +
107 114 0 0.1% 0.072 UG:1 --:6 +
36 169 0 0.1% 0.882 CG:7 +
156 160 1 0.1% 0.158 CG:5 UG:1 +
104 113 0 0.1% 0.058 CG:1 --:6 +
15 188 0 0.1% 0.501 UA:7 +
35 40 0 0.1% 0.939 CG:7 +
155 160 1 0.5% 0.136 CG:6 +
26 35 1 0.5% 0.639 GC:6 +
81 126 2 0.2% 0.101 GU:4 UG:1 +
40 47 2 0.2% 0.584 GC:2 GU:3 +
81 123 1 0.4% 0.129 GC:6 +
80 124 1 0.4% 0.460 GC:6 +
151 157 2 0.2% 0.073 UG:2 UA:3 +
70 135 2 0.2% 0.499 CG:3 UA:2 +
82 127 1 0.3% 0.077 UA:6 +
81 125 1 0.3% 0.339 GU:6 +
19 182 2 0.1% 0.249 CG:3 UA:2 +
67 72 2 0.1% 0.036 GC:4 GU:1 +
79 128 2 0.1% 0.028 UG:1 UA:4 +
81 124 1 0.2% 0.483 GC:6 +
149 160 1 0.2% 0.141 CG:6 +
14 191 1 0.1% 0.284 GC:6 +
26 34 1 0.1% 0.634 GC:6 +
148 160 1 0.1% 0.241 CG:6 +
44 49 1 0.1% 0.062 AU:6 +
39 48 2 0.2% 0.416 AU:5 +
35 170 2 0.2% 1.006 CG:5 +
24 36 2 0.1% 0.486 GC:5 +
20 25 2 0.1% 0.419 CG:5 +
....(((((((((({{(((..((((((................................(((((((......(((((((...{.((...(((((....................)))))..)),....)))))))..,.))))))).(((((((((....)))))))))......)))))).)))))).)).)))))).....
|
| Program name | Description |
|---|---|
| banana | Plot bending and curvature data for B-DNA |
| btwisted | Calculate the twisting in a B-DNA sequence |
| einverted | Find inverted repeats in nucleotide sequences |
| ovrnaalifold | Calculate secondary structures for a set of aligned RNAs |
| ovrnacofold | Calculate secondary structures of RNA dimers |
| ovrnacofoldconc | Calculate secondary structures of RNA dimers (concentrations) |
| ovrnacofoldpf | Calculate secondary structures of RNA dimers (partitioning) |
| ovrnadistance | Calculate distances between RNA secondary structures |
| ovrnaduplex | Predict RNA duplex (hybridization) sites and structure |
| ovrnaeval | Calculate energy of RNA sequences with a given secondary structure |
| ovrnaevalpair | Calculate energy of RNA sequences on given secondary structure |
| ovrnafold | Calculate min. energy RNA structure / pair probabilities (partition) |
| ovrnafoldpf | Calculate min. energy RNA structure / pair probabilities |
| ovrnaheat | Calculate specific heat of RNA melting |
| ovrnainverse | Find RNA sequences with a given secondary structure |
| ovrnalfold | Calculate locally stable secondary structures of RNAs |
| ovrnaplot | Draw RNA secondary structures |
| ovrnasubopt | Calculate suboptimal secondary structure of RNA |
| sirna | Find siRNA duplexes in mRNA |
| vrna2dfold | Calculate RNA structures and samples of k,l neighbourhoods |
| vrnaaliduplex | RNA duplex calculation for two sequence alignments |
| vrnaalifold | Calculate secondary structures for a set of aligned RNAs |
| vrnaalifoldpf | Calculate secondary structures for a set of aligned RNAs (partition) |
| vrnacofold | Calculate secondary structures of RNA dimers |
| vrnacofoldconc | Calculate secondary structures of RNA dimers (concentrations) |
| vrnacofoldpf | Calculate secondary structures of RNA dimers (partitioning) |
| vrnadistance | Calculate distances between RNA secondary structures |
| vrnaduplex | Predict RNA duplex (hybridization) sites and structure |
| vrnaeval | Calculate energy of RNA sequences with a given secondary structure |
| vrnaevalpair | Calculate energy of RNA sequences on given secondary structure |
| vrnafold | Calculate min. energy RNA secondary structures and pair probabilities |
| vrnafoldpf | Calculate min. energy RNA structures / pair probabilities (partition) |
| vrnaheat | Calculate specific heat of RNA melting |
| vrnainverse | Find RNA sequences with a given secondary structure |
| vrnalalifoldpf | Calculate secondary structures for a set of aligned RNAs (partition) |
| vrnalfold | Calculate locally stable secondary structures of RNAs |
| vrnalfoldz | Calculate locally stable secondary structures of RNAs plus zscore |
| vrnapkplex | Calculate RNA structures plus pseudoknots |
| vrnaplfold | Compute avg. pair probabilities for local base pairs in RNA sequences |
| vrnaplot | Draw RNA secondary structures |
| vrnasubopt | Calculate suboptimal secondary structures of RNAs |
Please report all bugs to the EMBOSS bug team (emboss-bug © emboss.open-bio.org) not to the original author.
